ZHIGAO S125D Diesel Screw Air Compressor

OVERVIEW：

FEATURES

1,Greater fuel efficiency and energy saving;

2,Air filtration system with vacuum indication for dust environments;

3,Compressor oil and engine coolant coolers to optimize performance and extend engine life;

4,Efficient compressor oil filter;

5,Fuel filter with water separator;

6,Easy to remove, translucent PE fuel tank.

TECHNICAL DATA

Technical Parameters of S125D Screw Air Compressor
Type	S125D
Name designation	Diesel screw air compressor
Nominal displacement	36m³/min
Rated discharge pressure	30bar
Maintain oil change rate	120L
Compressed series	2 Step
Engine type	QSZ13-C550-30 CUMMINS
Engine output	410kw
Fuel tank capacity	600L
Dimensions	422020002300mm
Total weight	5600kg
Air evacuation valve	G1-1/2 G2-1/2 inch
